Stage and Sound: I Can't Hear The Words!

- By Jon Burton



In sound engineering, fundamental principles often emerge from seemingly simple advice. One such cornerstone is elegantly straightforward: 'Point the speakers at the audience.' While this might appear obvious, this principle encapsulates crucial aspects of audio system design, acoustic behaviour, and the relationship between sound reproduction and human perception.

Let's start with the audience, what do they want to hear? I think for most of us the only complaint we ever receive as engineers is, I can't hear the words. Audiences like to sing along with their artists and appreciate and value vocal clarity. When we consider music, especially popular music, melody and lyrics are very important.

Melody in music is often carried by multiple instruments. These are blended, often with percussion instruments to provide a beat, to provide a cohesive whole. Singing adds another layer of melody, but also lyrical content, words, that we like to hear and to understand, even if the meaning may not be profound or interesting, we still like to hear them and often sing along.

Being able to hear the lyrics in a song often takes a greater degree of clarity than the melody. We can often pick out the tune but be frustrated we cannot understand the words. Our brains can follow the instruments, even when blended and not individually recognisable, as they all contribute to what we understand as music. The melody of the vocal joins this collection of tones to complete the picture. However, we are also trying to recognise words and meanings that are much harder to pick out, requiring a clarity that we may not need to follow melody alone. It is for this reason that as engineers we usually prioritise the vocal over all other musical instruments. We need to be able to hear the differences between the vowels and consonants, the sounds that make up the words we are trying to recognise.



Now, you may counter that you often listen to music where the words are in a different language you don't understand yet still enjoy. Yes, I would agree, however, our brains are programmed to recognise speech and will try and grasp for meaning even if just to discover it is not a meaning they have been trained to comprehend.

Speech requires the sound system to have clarity. It needs to be able to reproduce the frequency range of the human voice at a sufficient sound pressure level to be clearly heard by the audience. IEC 60268 is the international standard for objective rating of speech intelligibility and looks at the frequency range of 125Hz to 8kHz, a good starting point for discussion. The human voice can't sing that high, C6 is just over 1kHz, but the extra frequencies help to provide the timbre, the unique quality or tone colour that allows us to distinguish between different sounds, even when they have the same pitch, loudness, and duration. The higher frequencies help us to recognise the phonemes, the smallest units of sound that make up words in spoken language. The highest frequencies are also the hardest to project across a large audience, for many reasons.

When we set up our speaker system, which may be made up of two or three types of drivers, we need to think about what each section does. Many systems have a larger low-frequency driver, a mid-range speaker and a driver dedicated to the high frequencies. The low-frequency driver, often operating from 250Hz and below, covers the lower registers of the musical scale, providing depth or weight. The mid-range speaker is carrying most of the melody, probably up to about 2kHz. The high-frequency driver takes over here and provides us with the harmonics, the additional frequencies that give the voice its timbral quality, that helps us pick it out from the other instruments.

Modern sound reinforcement systems employ specialised drivers, each optimised for specific frequency bands. In a three-way system, the low-frequency driver handles frequencies typically below 250-300 Hz, reproducing fundamental bass notes, kick drums, and providing the foundation of the mix. The mid-frequency driver, operating from approximately 300 Hz to 2 kHz, reproduces the critical vocal fundamentals and primary melodic content of most instruments. The high-frequency driver manages frequencies above 2 kHz, delivering the overtones, transients, and harmonic content essential for articulation, and timbral definition.

As an experiment, if you can, turn off the different bands on your system and have a listen. What information are they carrying? Can you pick out the tune using just the mid-range? Yes? Can you hear the words? Listen to the high-frequency driver just on its own? What do you get? Some understanding of the words? But how much melody? What about the bass? What is it contributing? We need the entire range for a good sound, but without the high frequencies, we have a melody but little understanding of meaning.

If you then walk around your speaker stack, what can you hear? As you move away from the front you can still hear the bass and probably pick out the melody. As you get to the back the bass will still be there, but the melody will be harder to pick out, and your ability to hear the words will probably be lost.

The relationship between frequency and directivity follows a fundamental acoustic principle: lower frequencies exhibit omnidirectional radiation patterns due to their longer wavelengths. When the wavelength exceeds the dimensions of the source (the speaker cabinet) the sound pressure levels remain relatively consistent around it. As frequency increases, wavelengths shorten, and the sound naturally becomes more directional. At high frequencies, typically above 2kHz, we enhance this directivity by coupling drivers to acoustic horns, which control dispersion patterns and increase efficiency through acoustic impedance matching.

Look at your horn. What shape is it? This will dictate what area it can cover. This is usually designed to be wider than it is tall, audiences normally spread out over the horizontal rather than vertical plane. Have a listen to some quiet music. Walk slowly across the front of your cabinet until you begin to lose the hi-hats. This is the coverage of your driver. If this is not pointing at the audience, they cannot hear it. They may still pick up the melody, but they may struggle to hear the words. If so, they will let you know. It may be the only complaint you ever get, but it's the most important one, 'I can't hear the words'.

Profile: Jon Burton is a sound engineer with over thirty years of concert touring experience. Working with a wide range of artists, from Bryan Ferry to Radiohead, including 20 years as FOH engineer for The Prodigy. Having had no prior formal education in sound, in 2017 Jon completed an MSc in Music Technology. Jon is currently studying for a PhD at the University of Derby, UK, where he works as a Senior Lecturer in Entertainment Engineering. Jon is a founder member of HELA, an international certification for hearing health awareness at live music events. Jon is also a partner in the Laundry Rooms recording studio complex in Sheffield, UK.
